Power Source 220V 50-60Hz 1Ph
Motor Power 50 W
Power Requirement 400 W
Rotation Speed 98 RPM
Rim Diameter 8″ (200 mm) – 26″ (650 mm)
Rim Diameter (alu-s) 8″ – 23″
Wheel Diameter (max) with wheel-guard 34″ (850 mm)
Wheel Diameter (max) without wheel-guard 36″ (910 mm)
Rim Width (max) with wheel-guard 16″ (415 mm)
Rim Distance (alu-s /laser) 11.5 ” (290mm)
Wheel Weight (max) 90 Kg (198 Lbs)
Measuring Time 4 – 15 s.
Accuracy 1 gr.
Angular Accuracy 256 divisions (accuracy = 1,4 deg)
Monitor LCD SVGA 17″
Noise < 70dB (A)

VIDEOTRONIC V653. The revolution of wheel balancing.
Designed for the tyre specialists with heavy peak jobs, V653 offers maximum performances for wheel balancing, thanks to its innovative features. V653 is built around its Tilting System to grant perfect centering of every wheel with no efforts, and also offers all automatic features that improve accuracy and speed up the whole wheel balancing process.

A unique advantage: Tilt-system and horizontal mounting.
Centering the wheel perfectly and with no efforts becomes easy and minimizes come-backs!
On any normal wheel balancer, mounting the wheel needs a lot of attention by the operator, as centering the wheel is a critical operation in the whole balancing process. Proper centering is affected by the weight of the wheel and fatigue of the operator.

The Tilt-system of this balancer allows a wheel to be mounted horizontally on the wheel balancer, so that centering is always perfect, regardless of operator training, skill and fatigue.

Technologically unsurpassed and still easy to use.
Based on the Videotronic technology, the balancer is controlled by a Personal Computer, with Windows CE operating system. User can easily control all functions through an LCD monitor: with the use of graphics and icons, using the wheel balancer is absolutely intuitive. No confusing “frills”, no strange “gadgets”. Instead, a well-tested user-friendly interface with buttons and icons for a professional use. Fast, clear, effective.

Also, the software, stored on a Flash memory, can be upgraded in seconds. You can always take advantage of our continuous technical developments and make sure your product is never outdated!

Designed for top performances.
A base with four weights compartments, one compartment for tools (pliers, etc.). Weight tray also offers place for standard cones. Flanges can be placed laterally on the wheel balancer: six flange holders are provided.

Extra space for weights (9 trays) is provided on the back-mount weights-holder, which also offers an extra space for 7 cones/adapters.

The wheelguard with a new design reduces opening efforts and minimize space requirements dramatically.

Precision mechanics.
The heart of the balancer is built around the VQI 3-sensor system, a FASEP exclusive design, and with IFS system (integrated-flange shaft) for maximum centering accuracy.

It also comes with the new shaft 2003, allowing larger tires and rims and designed to work easily on wheels where adhesive weights are required, with a larger access to the inside of the rim, more then any other competitor.

Built to last (as strong as it looks!).
Every detail is designed and tested to grant long time of good working quality.
The Heavy Duty shaft allows 90kg of maximum weight on the shaft, a record unsurpassed. No competitor’s product can match it.
Bigger and tougher than any other competitor’s product !

Special features comes included
The PneuLock system let you performs a total balancing cycle much faster in comparison with the normal manual locking, and at the same time it assures a more precise centering.

The Laser System serves instead to get an accurate and fast job also in the case of balancing with adhesive weights. No more approximate ALU programs! 0-0 at the first spin assured!

Customized Special Versions
Do you have special request to fit your garage design or to impress your customer ? If you need a special version we can do it!

See this example: V653-Silver Red
