OEM Diagnostic Scan Tool technology- G-Scan 3
Features :
★Higher CPU performance
Equipped with a powerful Samsung Exynos 7420 Octa-core processor for ideal management of workshop operations, including keeping all vehicle records, customer information, and other necessary images and data.
★Smarter & Faster operating system
Based on the Android 6.0 system, this provides an improved user interface and experience for fast boot up, multi tasking, better networking and enhanced system security.
★Capacitive Touch Screen on 10.1″ LCD
User interface through capacitive touch screen technology provides an easy & most intuitive use of a diagnostic tool and its multiple functions. The high resolution TFT screen offers greater readability and convenient touch screen operation.
★Extensive Storage Capability
The internal flash memory of 64GB accommodates software applications and data for all brands with plenty of room to spare, and the external memory space up to 128GB allows an extensive amount of storage for saving images & recorded data.
★Pre & Post Diagnostic Report
Designed to easily create a diagnostic report. The Pre-scan report will highlight any issues that vehicles have, whilst the Post-Scan report will confirm that they have been resolved accurately.
★24V Commercial Vehicles
Designed to support the 24V commercial vehicle systems, make direct connection to trucks and buses.
★Wireless Connectivity
WIFI connection to the internet allows for smart updates, quick feedback, Teamviewer support, wireless printing, browsing and more.
★J2534 Pass Thru
Serves as a ‘Pass Thru’ device for programming ECU’s on both Hyundai and Kia vehicles (USA & Europe vehicles only)
★Rechargeable Battery
Equipped with a rechargeable 6300Ah battery. Besides the possibility to use the G scan 3 without external power for hours, it also enables the advanced diagnostic functions needed whilst cranking the engine.
Specification
Category | Specifications |
---|---|
CPU | Exynos 7420 Octa Core @ 2.1 GHz |
Operating System | Android 6.0 |
System Memory | Internal Flash 64GB, RAM 3GB |
External Memory | Micro SD Card (max. 128GB) |
LCD | 10.1″ TFT (1280 x 800 pixel) |
Input Devices | Capacitive Touch Screen, 3 Hard keys (Power, Function 1, Function 2) |
Camera | Rear 13Mp, AF, Flash Light |
Sound | Speaker (Mono), Microphone & Earphone Jack |
Rechargeable Battery | Li-ion Polymer, 6300mAh(3.7V), Hard Pack |
Operating Voltage | DC9-30v |
Sensors | Gyro-sensor, Acceleration sensor |
Dimension | 304x208x35.5mm |
External Port | USB 2.0 Host 1ea, Host & Slave 1ea |
Video out | HDMi |
Network | RJ45 Ethernet, Wifi 802.11 a/b/g/n, Bluetooth 4.0 |
AC/DC Adaptor
Category | Specifications |
---|---|
Input Power | 100-240V AC |
Frequency | 50/60Hz |
Input Current | 0.8A |
Output Voltage | 12V DC |
Output Current | 3 A |
